  • AN19DN0A5E020 NEMA 1 Starter by Eaton

AN19DN0A5E020 Freedom Series NEMA size 1 Starter Eaton Cutler-Hammer

$274.00
SKU:
AN19DN0A5E020
Condition:
New
Shipping:
Calculated at checkout
Current Stock:
1
Quantity:

Product Description

AN19DN0A5E020

  • Motor Starter
  • NEMA
  • Non Reversing
  • NEMA Size 1
  • NEMA Enclosure Type Open
  • Coil Volts 120
  • 50/60 Hz
  • Number of Poles 3
  • 27 Amps AC
  • Aux. Contact Configuration 1NO
  • 2 HP @ 1 Phase - 120V
  • 3 HP @ 1 Phase - 230V
  • 7-1/2 HP @ 3 Phase - 208V
  • 7-1/2 HP @ 3 Phase - 230V
  • 10 HP @ 3 Phase - 460V
  • 10 HP @ 3 Phase - 575V
  • Height (In.) 5.00
  • Width (In.) 5.00
  • Depth (In.) 7.50
  • Standards UL/ CSA
  • Includes Class 20 Solid State Ambient-Compensated Overload Relay and Instantaneous Magnetic Trip Mechanism

Warranty Information

- Breaker Outlet inspects all of our products prior fulfilling your order. New AN19DN0A5E020's come with a 1 year warranty. All Re-Certified AN19DN0A5E020's come with a 2 year warranty.
