SKU: 9001KP1G31-R
Barcode: 785901094487
- Free ground shipping in contiguous U.S. for carts over $100 & under 70lbs.
- Returns accepted within 30 days.
Couldn't load pickup availability
Overview
9001KP1G31
- STANDARD, ROUND TYPE
- 30 MM SIZE
- UL 508, CSA C22.2, CE APPROVAL
- NEMA 4/13, CLASS I DIV 2 GROUP A B C D, CLASS II DIV 2 GROUP E F G, CLASS III DIV 1 AND 2, IP66 ENCLOSURE
- THERMOPLASTIC POLYESTER LIGHT MODULE, ZINC OPERATOR BASE BODY MATERIAL
- CHROMIUM PLATED METAL BEZEL MATERIAL
- 110 TO 120 V AT 50/60 HZ TRANSFORMER LAMP INPUT TYPE
- 755 LAMP NUMBER
- PLASTIC LENS MATERIAL
- GREEN LENS COLOR
- FRESNEL LENS STYLE/SIZE
- HARMONY[T] BRAND
- APPLICABLE STANDARD EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C 852, JIS C 4520
- CONSTRUCTIONAL FEATURE WATER TIGHT, DUST TIGHT AND OIL TIGHT
- APPLICATION HAZARDOUS LOCATION
- WITH SCREW CLAMP TERMINAL
- 9001 MODEL
