AN16DN0AB NEMA Size 1 Starter Eaton Cutler-Hammer 120V
AN16DN0AB NEMA Size 1 Starter Eaton Cutler-Hammer 120V
SKU: AN16DN0AB
Barcode: 782113971704
1 in stock
- Free ground shipping in contiguous U.S. for carts over $100 & under 70lbs.
- Returns accepted within 30 days.
Couldn't load pickup availability
Overview
AN16DN0AB
- Full Voltage, Non-Reversing Type
- NEMA 1 Size
- 27 Amp Current Rating
- Open Enclosure Type
- NEMA Construction Standard
- 110 Volt Ac At 50 Hertz, 120 Volt Ac At 60 Hertz Coil Voltage
- 1No Auxiliary Contact
- 2 Hp At 115 Volt 1-Phase, 3 Hp At 230 Volt 1-Phase, 7-1/2 Hp At 208/240 Volt 3-Phase, 10 Hp At 380/480/600 Volt 3-Phase Power Rating/Voltage
- Bi-Metallic Ambient Compensated Overload Relay Overloads
- 1 Or 3 Phase
- Cutler-Hammer Brand
- Number Of Poles 3
- Mounting Type Horizontal
- Approval UL, CSA
- Freedom, AN16 Model
- New
