B115HH Siemens HBL Molded Case Circuit Breaker 15 A 1 Pole 120/240 VAC BL 125A Frame Thermal Magnetic Load Side Lug 65 kA
B115HH Siemens HBL Molded Case Circuit Breaker 15 A 1 Pole 120/240 VAC BL 125A Frame Thermal Magnetic Load Side Lug 65 kA
Couldn't load pickup availability
Overview
Siemens low voltage molded case circuit breakers panelboard mounting 240 V circuit breakers - type BL, 1-Pole, 120V ac are circuit protection molded case circuit breakers. Type: HBL application: electrical distribution standard: UL 489 voltage rating: 120V amperage rating: 15A trip range: thermal magnetic interrupt rating: 65 AIC number of poles: 1P.
- 120, 120/240, 240vac max
- UL listed, file # E82615
- CSA and NOM certified
- HACR rated
- 40C calibration
- Thermal / magnetic trip
- Molded case switch, 2 pole 30 - 60 amperes
- HID lighting, 1 and 2 pole 15, 20, 30 amperes
- SWD duty - 1 pole 15 - 20 amperes
