Representative image.
Siemens
B250 Siemens BL 50A 2-Pole Bolt-On Circuit Breaker
B250 Siemens BL 50A 2-Pole Bolt-On Circuit Breaker
Regular price
$16.00 - $29.69
Sale price
$29.69
Regular price
Shipping calculated at checkout.
Couldn't load pickup availability
Overview
Siemens B250 is a common-trip, bolt-on thermal-magnetic circuit breaker for compatible panelboards. It provides overload and short-circuit protection.
Specifications
| Brand | Siemens |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| AC Voltage Rating | 120/240 VAC |
| Current Rating | 50 A |
| Interrupt Rating | 10 kA at 120/240 VAC |
| Trip Type | Fixed; Common Trip |
| Trip Mechanism | Thermal Magnetic |
| Frequency Rating | 50/60 Hz |
| Number of Poles | 2 |
| Frame Size | BL 125A |
| Actuator Type | Toggle |
| Wire Size | 8 to 4 AWG (Aluminum); 8 to 6 AWG (Copper) |
| Terminal Type | Load Side Lug |
| Mounting Type | Bolt-On |
| Operating Temperature Rating | 40 °C |
| Short Circuit Protection (Yes/No) | Yes |
| Overload Protection (Yes/No) | Yes |
| For Use With | Panelboards; Load Center |
| Application | Electrical Distribution |
| Certifications | UL 489; UL E82615; CSA C22.2 NO. 5-16; NMX-J266-ANCE-2016; HACR Rated; SWD Rated; NOM Certified |
| Weight | 0.639 lb |
| Package Quantity | 1 Piece |
| Country of Origin | Mexico |
| Manufacturer Part Number | B250 |
| Series | BL |
| Dimensions | 3 × 2 × 3.5625 in |
