SKU: E50AM1
Barcode: 782113343921
- Free ground shipping in contiguous U.S. for carts over $100 & under 70lbs.
- Returns accepted within 30 days.
Couldn't load pickup availability
Overview
E50AM1
- HEAVY DUTY PLUG IN TYPE
- SP-1NO-1NC CONTACT CONFIGURATION
- 5 PIN RECEPTACLE CONNECTION TYPE
- 2 POSITION, MAINTAINED, SNAP OPERATION TYPE
- 120/240/480/600 VAC 10 AMPERE, 125/250 VDC 1 AMPERE CONTACT RATING
- UL, CSA, CE, TUV APPROVAL
- NEMA 1/3/3S/4/4X/6/6P/13, IP67 ENCLOSURE
- DIE CAST ZINC BODY MATERIAL
- 14 TO 200 DEG F OPERATING TEMPERATURE
- 3 LB-INCH OPERATING FORCE
- 50 DEG DIFFERENTIAL TRAVEL
- NO ACTUATOR/HEAD TYPE
- 50 DEG PRETRAVEL
- 90 DEG TOTAL TRAVEL
- APPLICABLE STANDARD IEC 947-5-1
- E50SB MODEL
New, no box.
