Eaton

FDCE316036 Electronic Circuit Breaker Type HFDE / 310+ GFI

SKU: FDCE316036

Barcode: 786685237213

Call (800) 321-8998 for pricing and availability.

Free ground shipping in contiguous U.S. for carts over $100 & under 70lbs.
Returns accepted within 30 days.

Overview

Specifications:

Eaton Cutler-Hammer OEM
Series C MCCB
Panel mount
160 Ampere
3 Pole
100k rated @ 480VAC
600 VAC
Electronic Trip
Adjustable Trip
Approval UL, CSA. CE
Mfg Status: Available
Industrial

FDCE316036 3 Pole 100k, 60A thru 160A, 600V Intergrated within this breaker features include adjustable Long-Time setting, Short-Time, Adjustable-Ground and Instantaneous Ground with status signal and alarm. Electronic, Molded Case, F Frame, 240/480/600 Vac At 50/60 Hz, 250 Vdc (Ul 489), 225 Ampere, 3 Pole, Interrupting Rating 200 Kiloampere At 240 Vac, 100 Kiloampere At 480 Vac, 35 Kiloampere At 600 Vac, 22 Kiloampere At 250 Vdc (Ul 489), Terminal Aluminum/Copper Standard Pressure Line And Load Terminal, Size 4.13 Inch W X 3.38 Inch D X 6 Inch H, Fdce Model, Trip Type Digitrip Rms 310 Electronic Trip Lsig. Comes complete with installation instructrions. FDCE316036.
