HGL36100SA Shunt Trip Square D Circuit Breaker
HGL36100SA Shunt Trip Square D Circuit Breaker
SKU: HGL36100SA
Barcode: 785901493242
- Free ground shipping in contiguous U.S. for carts over $100 & under 70lbs.
- Returns accepted within 30 days.
Couldn't load pickup availability
Overview
HGL36100SA
Includes 120V Shunt Trip device. Amp: 100 3 Pole, Interrupting Rating 65 Kiloampere At 240 VAC 120V Shunt Trip Thermal Magnetic H Frame 240 VAC At 50/60 HZ, 480 VAC Star/277 VAC At 50/60 HZ, 480 VAC At 50/60 HZ, 600 VAC Star/347 VAC At 50/60 HZ, 600 VAC At 50/60 HZ Underwriters Lab/CSA/Nom, 240/415 VAC At 50/60 HZ (Iec), 250 VDC 35 Kiloampere At 480 VAC Star/277 VAC Or 480 VAC, 18 Kiloampere At 600 VAC Star/347 VAC Or 600 VAC (Underwriters Lab/CSA/Nom) 65 Kiloampere At 240 VAC, 35 Kiloampere At 415 VAC IED, 20 Kiloampere At 250 VDC Terminal Line Lug, Load Lug, Size 4.12 Inch W X 4.36 Inch D X 6.4 Inch H.
