QMJ361T Square D Twin Panel Mount Switch 30A 600V
QMJ361T Square D Twin Panel Mount Switch 30A 600V
SKU: QMJ361T-R
Barcode: 785901209072
- Free ground shipping in contiguous U.S. for carts over $100 & under 70lbs.
- Returns accepted within 30 days.
Couldn't load pickup availability
Overview
QMJ361T
- Twin 30A Fusible Panel Switch
- Square D
- Twin Type
- 4.5 Inch H Size
- QMB Series Panelboard And Qmj Fusible Switch Used On
- 14 To 2 Awg (Aluminum/Copper) Wire Size
- Ul Approval
- 240/480/600 Vac, 250 Vdc Voltage Rating
- 30 Ampere Current Rating
- 3 Hp At 240 Vac 3 Phase, 5 Hp At 480 Vac 3 Phase, 7 1/2 Hp At 600 Vac 3 Phase (Standard)
- 7 1/2 Hp At 240 Vac 3 Phase, 15 Hp At 480 Vac 3 Phase, 20 Hp At 600 Vac 3 Phase (Maximum)
- 5 Hp At 250 Vdc Power Rating
- 3 Pole(S)
- Mounting Type Panel/Surface
- Material Steel
- QMJ Model
- Re-certified
