QO2501021 Square D 2 Pole 50 Amp Circuit Breaker with Shunt Trip
QO2501021 Square D 2 Pole 50 Amp Circuit Breaker with Shunt Trip
SKU: QO2501021
Barcode: 785901494010
6 in stock
- Free ground shipping in contiguous U.S. for carts over $100 & under 70lbs.
- Returns accepted within 30 days.
Couldn't load pickup availability
Overview
QO2501021
- SQUARE D
- SHUNT TRIP BREAKER 120V
- BRANCH TYPE
- NQ SERIES PANELBOARD USED ON
- UL, CSA APPROVAL
- APPLIANCE, LIGHTING APPLICATION
- 120/240 VAC AT 50/60 HZ (UL/CSA), 48 VDC VOLTAGE RATING
- 10 KILOAMPERE AT 120/240 VAC (UL/CSA), 5 KILOAMPERE AT 48 VDC INTERRUPTING RATING
- 50 AMPERE CURRENT RATING
- 2 POLE(S)
- FRAME TYPE Q
- MOUNTING TYPE PLUG-IN
- SIZE 2.25 INCH W X 2.91 INCH D X 3 INCH H
- TRIPPING METHOD THERMAL MAGNETIC, COMMON TRIP
- 14 TO 8 AWG (ALUMINUM/COPPER)
- WITH VISI-TRIP[R] INDICATOR, 120/208/240 VAC SHUNT TRIP
- NEW
