TED134015WL 3 Pole 15 Amp General Electric Circuit Breaker, 480 Volt
TED134015WL 3 Pole 15 Amp General Electric Circuit Breaker, 480 Volt
7 in stockReady to ship from our warehouses
Couldn't load pickup availability
Overview
The TED134015WL is a 15 A, 3-pole ABB / GE TED E150-frame molded-case circuit breaker rated for 480 VAC. This breaker has a fixed thermal-magnetic trip and includes copper/aluminum line and load lugs.
- 15 A, 3-pole TED E150 circuit breaker
- 480 VAC class; thermal-magnetic protection
- Cu/Al line and load lugs included
- Verify interrupting rating at your system voltage and equipment compatibility before installation
WL and non-WL models are comparable TED breakers but differ in supplied lug configuration. Confirm exact part number before ordering.
Specifications
| Brand | ABB / GE |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Series | TED |
| Frame Size | E150 |
| AC Voltage Rating | 480 V |
| Current Rating | 15 A |
| Trip Mechanism | Thermal Magnetic |
| Number of Poles | 3 |
| Mounting Type | Panel |
| Lug Configuration | Line and Load Lugs |
| Manufacturer Part Number | TED134015WL |
| UPC | 783164063011 |
