Product Description
FD2200
- Eaton Cutler-Hammer OEM
- Series C MCCB
- Panel mount
- 200 Ampere
- 2 Pole
- 25k rated @ 480VAC
- 600 VAC
- Thermal magnetic
- Fixed Trip
- Approval UL, CSA. CE
- Mfg Status: Available
- Industrial
FD2200, 2P 200A 240V/480V/600V Molded Case Circuit Breaker by Cutler Hammer and formerly of Westinghouse, Thermal Magnetic, F Frame, 600 Vac At 50/60 Hz, 250 Vdc, 40 Deg C, 2 Pole, Interrupting Rating 65 Kiloampere At 240 Vac, 35 Kiloampere At 480 Vac, 18 Kiloampere At 600 Vac, 10 Kiloampere At 250 Vdc, 65 Kiloampere At 220/240 Vac, 35 Kiloampere At 380/415/440 Vac, 18 Kiloampere At 500 Vac, 10 Kiloampere At 250 Vdc (Iec), Terminal Standard Pressure Line Terminal, Standard Pressure Load Terminal, Size 4.125 Inch W X 3.375 Inch D X 6 Inch H, Approval Ul, Fd Model, Applicable Standard Iec 157-1. Use in circuit protection for overloads. FD2200 two pole unit with load lugs.
