Product Description
LC36600
• Cat. No. : LC36600
• Alternate Part No. : LC-36600
• Product Type : Molded Case Circuit Breaker
• Model : LC
• Frame Type : L
• No. of Poles : 3-Pole
• Phase : 3-Phase
• Amperage : 600-Amps
• Voltage Rating : 600V at 50/60Hz
• Connection: I-Line Style Plug-In
• Trip Type : Thermal Magnetic
• Functions : (LI) Long-Time and Instantaneous
• Trip Range 3000 Amp (Low) 4200 Amp (High)
• Interrupting Rating : 65kAIC at 480VAC
• Sub Brand : I-Line
• Feature : Extra High Interrupting
• Mounting Style : Plug-On
• Approvals : UL (Listed) CSA (Certified)
• Current Limiting
• Size 7.5 Inch W X 6.74 Inch D X 11.86 Inch H
• Application : Industrial Enclosures Panelboards Switchboards Busway Plug-In Units Combination Starters and Motor Control Centers
• Re-certified
3 Pole 600 Ampere I-Line Molded Case, Thermal Magnetic, L Frame, 240 VAC At 50/60 HZ, 480 VAC Star/277 VAC At 50/60 HZ, 480 VAC At 50/60 HZ, 600 VAC Star/347 VAC At 50/60 HZ, 600 VAC At 50/60 HZ (Underwriters Lab/CSA/Nom), 415 VAC At 50/60 HZ (Iec), 3 Pole, Interrupting Rating 100 Kiloampere At 240 VAC, 65 Kiloampere At 480 VAC Star/277 VAC Or 480 VAC, 35 Kiloampere At 600 VAC Star/347 VAC Or 600 VAC (Underwriters Lab/CSA/Nom), 65 Kiloampere At 415 VAC (Iec), Terminal Plug On, Size 7.5 Inch W X 6.74 Inch D X 11.86 Inch H, Approval Underwriters Lab, CSA, Ce, I-Line Brand, LC Model, Applicable Standard W-C-375b/Gen, LC36600 Extra High Interrupting breaker.
