New AMB24SR Belimo Non-Sprung Actuator

Product Description

AMB24SR

• Damper Actuator
• Non-Sprung Return
• 240V AC/DC
• Belimo Brand
• Torque 180 in-lb [20 Nm]
• New

REMARKS: For proportional modulation of dampers in HVAC systems. Actuator sizing should be done in
accordance with the damper manufacturer’s specifications.
The actuator is mounted directly to a damper shaft up to 1.05” in diameter by means of its
universal clamp, 1/2” self-centered default. A crank arm and several mounting brackets are
available for applications where the actuator cannot be direct coupled to the damper shaft.
The actuator operates in response to a 2 to 10 VDC, or with the addition of a 500 Ω resistor, a 4
to 20 mA control input from an electronic controller or positioner. A 2 to 10 VDC feedback signal
is provided for position indication or primary and secondary applications.
