Product Description
GHB2060
- Eaton Cutler-Hammer
- OEM
- MCCB
- Bolt-on
- 60 Ampere
- 2 Pole
- 14k rated @ 480VAC
- 277/480 VAC
- Thermal Magnetic Trip
- Fixed Trip
- Approval UL, CSA. CE
- Mfg Status: Available
- Industrial
GHB2060 60A 2 Pole molded case branch circuit breaker, thermal magnetic, G frame, For use in PRL panelboards. 480 VAC star/277 VAC at 50/60 Hz, 125/250 vdc, 40 Deg C, 2 pole, interrupting rating 65 kiloampere at 240 VAC, 14 kiloampere at 480 VAC star/277 VAC, 14 kiloampere at 125/250 VDC, terminal screw type clamp, GHB model, applicable standard as 2184, BS 4752, IEC 157-1, NEMA ab-1, NF C 63-120, sabs 156, sev 157-1, VDE 0660. This breaker is compact and economical for industrial use. Ideal use with machinery, welding equipment, blowers, sanders or water pumps. Previously made by Westinghouse.
